200kgf

500kgf

1000kgf

2000kgf

5000kgf

8000kgf

環境溫度
Ambient temperature

0~40℃無結露 No dewing at 0~40℃

電源接入
Power access

單相AC220V Single phase AC220V

三相AC380V 3-phase AC380V

功率消耗
Power consumption

300W

500W

800W

2100W

4650W

5650W

壓裝模式
Pressing mode

1.恒定壓裝速度，設定精確位置停止 2.恒定壓裝速度，設定精確壓力停止 3.恒定壓裝速度，設定精確位移停止
1. Constant pressing speed and setting the accurate location for stop 2. Constant pressing speed and setting the accurate pressure for stop 3. Constant pressing speed and setting the accurate displacement for stop

壓裝程序
Pressing programs

內置100套壓裝程序，可任意設定、調用
100 built-in pressing programs, available for setting and calling as
needed;

人機界面
Human machine interface (HMI)

標配65536色7寸中文觸摸顯示屏
Standard 65536-color 7in touch screen (Chinese)

控制方式
Control mode

100Mbps高速通訊功能的模塊化PLC+專用控制單元
Modular PLC with 100Mbps high speed communication + Dedicated control unit

驅動方式
Driving mode

精密AC伺服電機驅動七維精細研磨滾珠絲桿實施壓裝作業
The precision AC servo motor drives the 7D fine grinding ball screw to realize the pressing operation.

I/O接口 I/O port

USB2.0,可用于相關數據下載與上傳
USB2.0 for data download and upload

外設接口
External port

本機與外部設備間的開關量信息采用12針航空接頭連接，可實現外部控制聯機動作（選配件）
The switch data between the machine and the outside equipment
can be transmitted via the 12-pin aviation connector, to realize the
interlocking with outside control (optional).

上沖模柄孔
Upper die handle hole

Φ8mm

Φ16mm

Φ16mm

Φ20mm

Φ25mm

Φ30mm

壓力輸出
Pressure output

標稱出力Nominal output

200kgf

500kgf

1000kgf

2000kgf

5000kgf

8000kgf

適用范圍Applicable scope

全量程的10%-100% 10%-100% of the full range

設定單位Setting unit

0.1 kgf

壓力精度Pressure accuracy

1%F.S

重復精度Reproducible accuracy

1%F.S（在溫度、工況、負載等環境因素相同時的檢測值）
1%F.S (the detection value under the same temperature, operation
condition, load and other environment factors)

位移行程
Displacement travel

標稱行程
Nominal stroke

50/100mm，特殊規格接受訂制
50/100mm, available for
customizing for the special
specification

150/200/250mm，特殊規格接受訂制
150/200/250mm, available for
customizing for the special
specification

設定單位Setting unit

0.1 kgf

重復精度
Reproducible accuracy

0.01 mm（在溫度、工況、負載等環境因素相同時的檢測值）
0.01mm (the detection value under the same temperature, operation
condition, load and other environment factors)

直線速度
Linear speed

快進速度Rapid forward speed

0.1-160mm/s

0.1-200mm/s

探測速度Detection speed

0.1-20mm/s

0.1-30mm/s

壓裝速度Pressing speed

0.1-35mm/s

0.1-50mm/s

返回速度Backward speed

0.1-160mm/s

0.1-200mm/s

設定單位Setting unit

0.01 mm/s

保壓時間
Pressure retention time

*大設定Maximum setting

99.9sec

推薦值 Recommended value

<10sec

設定單位Setting unit

0.1 sec
