(1)pall頗爾濾芯要裝在泵的吸油口處：

泵的吸油路上一般都安裝有表面型濾油器，目的是 濾去較大的雜質微粒以保護液壓泵，此外濾油器的過濾能力應為泵流量的兩倍以上，壓力損失小于0.02MPa。

(2)pall濾芯安裝在泵的出口油路上：

此處安裝濾油器的目的是用來濾除可能侵入閥類等元件的污染物。其過濾精度應為10～15μm，且能承受油路上的工作壓力和沖擊壓力，壓力降應小于0.35MPa。同時應安裝

安全閥以防濾油器堵塞。

(3)pall濾芯安裝在系統的回油路上：這種安裝起間接過濾作用。一般與過濾器并連安裝一背壓閥，當過濾器堵塞達到一定壓力值時，背壓閥打開。

(4)pall濾芯安裝在系統分支油路上。

(5)pall濾芯單獨過濾系統：大型液壓系統可專設一液壓泵和濾油器組成獨立過濾 回路。

pall濾芯液壓系統中除了整個系統所需的濾油器外，還常常在一些重要元件(如伺服閥、精密節流閥等)的前面單獨安裝一個專用的精濾油器來確保它們的正常工作。

性能指標頗爾PALL濾芯 Pall 濾芯型號：HC9601 FKP 13H TD-FILTER 濾芯型號：T9601 H 003 BN / Z （1） （2） （3） （4） （5）說明：（1）系列號 : （2）壓力：H-32MPa M-16MPa C-3.0MPa L-1.6MPa （3）精度：1-3um 3-5 um 5-12 um 20-25 um…….. (4) 材料：玻纖濾紙-BN 不銹鋼編織網-W 木漿濾紙-P 不銹鋼燒結網-V （5）密封材料：Z-氟膠圈 D-丁晴膠 HC0101FKP18H-HC0101FKN18H-HC0101FKS18H-HC0101FKT18H HC0101FKP36H-HC0101FKN36H-HC0101FKS36H-HC0101FKT36H HC2206FKP3H-HC2206FKN3H-HC2206FKP6H-HC2206FKN6H HC2207FKP3H-HC2207FKN3H-HC2207FKP6H-HC2207FKN6H HC2208FKP4H-HC2208FKN4H-HC2208FKP6H-HC2208FKN6H HC2216FKP4H-HC2216FKN4H-HC2216FKP6H-HC2216FKN6H HC2217FKP4H-HC2217FKN4H-HC2217FKP6H-HC2217FKN6H HC2218FKP4H-HC2218FKN4H-HC2218FKP6H-HC2218FKN6H HC2233FKP6H-HC2233FKN6H-HC2233FKP13H-HC2233FKN13H HC2235FKP6H-HC2235FKN6H-HC2235FKP10H-HC2235FKN10H HC2236FKP6H-HC2236FKN6H-HC2236FKP10H-HC2236FKN10H HC2237FKN6H-HC2237FK6H-HC2237FKN13H-HC2237FKP13H HC2238FKN6H-HC2238FKP6H-HC2238FKN10H-HC2238FKP10H HC2252FKP10H-HC2252FKN10H-HC2252FKN19H-HC2252FKP19H HC2253FKN8H-HC2253FKP8H-HC2253FKN16H-HC2253FKP16H HC2254FKN8H-HC2254FKP8H-HC2254FKN16H-HC2254FKP16H HC2256FKN6H-HC2256FKP6H-HC2256FKN10H-HC2256FKP10H HC2257FKN6H-HC2257FKP6H-HC2257FKN10H-HC2257FKP10H HC2285FKN12H-HC2285FKP12H-HC2285FKN15H-HC2285FKP15H HC2295FKN18H-HC2295FKP18H-HC2295FKN136H-HC2295FKP36H HC2618FKN18H-HC2618FKP18H-HC2618FKN36H-HC2618FKPP36H HC6200FKN4H-HC6200FKP4H-HC6300FKN8H-HC6300FKP8H HC6300FKN26H-HC6300FKP26H-HC6300FKN13H-HC6300FKP13H HC6300FKN16H-HC6300FKP16H-HC6400FKN8H-HC6400FKP8H HC6400FKN13H-HC6400FKP13H-HC6400FKN26H-HC6400FKP26H HC6500FKN13H-HC6500FKP13H-HC6500FKN16H-HC6500FKP16H HC6500FKN26H-HC6500FKP26H-HC7400SKS4H-HC7400SKS8H HC7500SKS4H-HC7500SKS8H-HC8200FKN8H-HC8200FKP8H HC8200FKN13H-HC8200FKP13H-HC8200FKN16H-HC8200FKP16H HC8300FKN8H-HC8300FKP8H-HC8300FKN16H-HC8300FKP26H HC8300FKN39H-HC8300FKP39H-HC8314FKP16H-HC8314FKN39H HC8304FKN16H-HC8304FKP16H-HC8304FKN39H-HC8304FKP39H HC8400FKN8H-HC8400FKP8H-HC8400FKN16H-HC8400FKP16H HC8400FKN26H-HC8400FKP26H-HC8400FKN39H-HC8400FKP39H HC8500FKN8H-HC8500FKP8H-HC8500FKN13H-HC8500FKP13H HC8500FKN26H-HC8500FKP26H-HC8700FKN4H-HC8700FKP4H HC8700FKN8H-HC8700FKP8H-HC8900FKN8H-HC8900FKP8H HC8900FKN13H-HC8900FKP13H-HC8900FKN16H-HC8900FKP16H HC8900FKN26H-HC8900FKP26H-HC8900FKN39H-HC8900FKP39H HC8904FKN8H-HC8904FKP8H-HC8904FKN13H-HC8904FKP13H HC8904FKN26H-HC8904FKP26H-HC8904FKN39H-HC8904FKP39H HC9020FKN4H-HC9020FKP4H-HC9020FKN8H-HC9020FKP8H HC9021FKN4H-HC9021FKP4H-HC9021FKN8H-HC9021FKP8H HC9100FKN4H-HC9100FKP4H-HC9100FKN8H-HC9100FKP8H HC9100FKN13H-HC9100FKP13H-HC9104FKN8H-HC9104FKP8Z HC9104FKN13H-HC9104FKP13Z-HC9104FKN16H-HC9104FKP16Z HC9400FKN13H-HC9400FKP13H-HC9400FKN26H-HC9400FKP26H HC9400FKN39H-HC9400FKP39H-HC9404FKN13H-HC9404FKP13H HC9404FKN26H-HC9404FKP26H-HC9404FKN39H-HC9404FKP39H HC9600FKN4Z-HC9600FKP4H-HC9600FKN8Z-HC9600FKP8H HC9600FKN13Z-HC9600FKP13H-HC9600FKN16Z-HC9600FKP16H HC9601FKN4H-HC9601FKP4H-HC9601FKN8H-HC9601FKP8H HC9601FKN13H-HC9601FKP13H-HC9601FKN16H-HC9601FKP16H HC9604FKN8H-HC9604FKP8H-HC9604FKN13H-HC9604FKP13H HC9604FKN16H-HC9604FKP16H-HC9606FKN4H-HC9606FKP4H HC9606FKN8H-HC9606FKP8H-HC9606FKN13H-HC9606FKP13H HC9650FKN8H-HC9650FKP8H-HC9650FKT8H-HC9650FKP13H HC9650FKN16H-HC9650FKP16H-HC9651FKN8H-HC9651FKP8H HC9700FKN9H-HC9700FKP9H-HC9700FKN18H-HC9700FKP18H HC9700FKN27H-HC9700FKP27H-HC9701FKN9H-HC9701FKP9H HC9800FKN4H-HC9800FKP8H-HC9800FKN13H-HC9800FKP13H HC9801FKN8H-HC9801FKP13H-HC9901FKN13H-HC9901FKP13H HC9901FKN26H-HC9901FKP26H-HC9901FKN39H-HC9901FKP39H UE219AT4H-UE219AT8H-UE219AT13H-UE219AT20H UE319AT8H-UE319AT13H-UE319AT20H-UE319AT40H UE619AT20H-UE619AT40H-HC4704FKN8H-HC4704FKP8H HC4704FKN13H-HC4704FKN16H-HC4754FKN8H-HC4754FKN13H HC4754FKN16H-HC4754FKN26H-- 1200498 1202846 1203126 1202845 1201652 HC4754FKN16H HC4754FKN26H HC4754FKN13H HC4754FKN8H HC4754FKP8H HC4754FKP13H HC4754FKP16H HC4754FKP26H HC4754FKZ8H HC4754FKZ13H HC4754FKZ1
